The TCB-NC Temperature Controller with Compact Size and High Precision, available through X-Meritan and manufactured in our China factory, is a next-generation industrial temperature controller featuring a compact design, high-precision control, extensive functionality, and exceptional reliability. It is designed for industrial automation applications with stringent temperature and precision requirements. Whether for precision laboratory instruments, complex semiconductor equipment, or renewable energy production, it provides stable and accurate temperature control, making it an ideal choice for improving equipment performance and product quality.
Small size, high power. Extremely compact, with high space utilization. It saves installation space compared to similar products and is perfectly suited for dense control cabinets and micro equipment.The clear display and user-friendly menu navigation make parameter settings, mode switching and status monitoring clear at a glance. The simple and intuitive operation allows even non-professionals to quickly get started.It also has excellent anti-interference ability and has passed strict industrial-grade electromagnetic compatibility tests to ensure stable operation in complex industrial sites and accurate data.
|
Board Supply Voltage |
4.5V - 27V |
|
Recommendation |
A standard 5V-24V switching power supply is recommended. The TEC’s rated voltage should be equal to or slightly greater than the supply voltage. If the TEC’s rated voltage is less, it is acceptable; simply set the maximum output ratio. |
|
Board Supply Current |
Determined by the TEC’s maximum operating power. |
|
TEC Voltage |
2V - 24V (depending on the supply voltage) |
|
TEC Current |
10A @ 24V; 12A @ 12V |
|
Temperature Sensor |
10K NTC |
|
Temperature Accuracy |
±0.01°C |
|
NTC Temperature Range |
-60°C to +170°C |
|
PT100/PT1000 Temperature Range |
-60°C to +212°C |
|
Operating Temperature |
-40°C to +45°C |
|
Storage Temperature |
-40°C to +60°C |
|
Operating Humidity |
0% - 95% RH |
|
Default Factory Setting |
25°C |
|
Dimensions |
60mm x 42mm |
|
Height |
23mm total (18.5mm above board, 3mm below board for pins, board thickness 1.5mm) |
How to calibrate PID parameters?
Set the integral and differential terms to zero. Gradually increase the proportional gain Kp until the system exhibits slight oscillation, then reduce Kp until the oscillation subsides. Next, appropriately reduce the integral time Ti to eliminate steady-state error and prevent system instability. Finally, introduce the differential time Td to suppress oscillation and improve response speed, but be mindful of noise interference. Throughout this process, iterative adjustments should be made based on the actual system response until the desired control effect is achieved. Alternatively, you can contact our customer service staff for specialized technical guidance.
What are the unique advantages of TCB-NC compared to traditional temperature control systems?
Compared to traditional temperature control systems, our product offers higher temperature control accuracy, more flexible sensor compatibility, and a smaller size. It requires no external auxiliary equipment, making it easier to integrate.
